Type ADU01
Type ADU01 is a circular air diffusion unit for displacement ventilation. The armature has a circular duct connection with sleeve dimension.
The unit is fitted with diffusion nozzles which make it possible to change the geometry of the near zone. The unit is maintenance free and there is no risk of clogging.
Dimensions
| Size | A | D | H | Weight (kg) |
| 1207 | 250 | 125 | 710 | 5.0 |
| 1607 | 300 | 160 | 710 | 7.5 |
| 2010 | 360 | 200 | 970 | 13 |
| 2510 | 400 | 250 | 970 | 18 |
| 3115 | 520 | 315 | 1490 | 35 |
| 4020 | 630 | 400 | 2010 | 58 |
| 5020 | 730 | 500 | 2010 | 78 |
| 6320 | 830 | 630 | 2010 | 106 |
The sound level is specified at room damping of 4dB, corresponding to the damping in a room with a room constant of 10 m2 SABINE measured in the reverberation field.
